Specifications
| Signal system: | Pal |
| Image sensor: | 1/2.9” 2MP Digital Image Sensor |
| Effective pixel: | ＞1920(H)x1080(V) |
| Horizontal resolution: | 1080P @25FPS |
| Ir : | SMT Smart IR 12 LED , 850nm, IR Distance 10-25 Mtr |
| Lens furnished: | 3.6mm,2 Mega Pixel Lens; Angle of View: 70.9° |
| Lens interface: | M12 |
| Signal/noise ratio: | More than 60db |
| Shutter control: | 1/50 sec to 1/10,000 sec |
| Min illumination: | ‘0.001Lux @ (F1.2,AGC ON), 0 Lux (IR LED On) |
| Synchronisation: | Internal |
| White balance: | Auto |
| Back light compensation: | Auto |
| Gain control: | Auto |
| Video output signal: | Hd Analog Output |
| Transmission distance: | Up to 500m over coaxial cable |
| Operating conditions: | -10°C ~ +60°C, Humidity 90% or less (non-condensing) |
| Power supply: | DC 12V ± 10% |
| Current, power consumption: | 250ma , Max 3.5W |
| DIMENSION (lxwxh), WEIGHT: | 110mm*110mm*88mm, 270g |
