3.6mm Dome Camera (2 MP) Z.CC.CA.IRDO.HDTV20D.321080

3.6mm DOME CAMERA (2 MP) Z.CC.CA.IRDO.HDTV20D.321080

Key Features

• 1/2.9″ 2 MP Hi-Resolution Image Sensor
• Progressive Scanning
• 1080P Resolution with HDAVI Technology
• Long distance real-time transmission
• 3.6 mm Lens 2 MegaPixel Lens
• IR LED Range 10-25m
• Supports ultra-low illumination
• True Day Night with IR Cut Filter (ICR)
• IP66 Compliant
• UTC Control


Signal system: Pal
Image sensor: 1/2.9” 2MP Digital Image Sensor
Effective pixel: >1920(H)x1080(V)
Horizontal resolution: 1080P @25FPS
Ir : SMT Smart IR 12 LED , 850nm, IR Distance 10-25 Mtr
Lens furnished: 3.6mm,2 Mega Pixel Lens; Angle of View: 70.9°
Lens interface: M12
Signal/noise ratio: More than 60db
Shutter control: 1/50 sec to 1/10,000 sec
Min illumination: ‘0.001Lux @ (F1.2,AGC ON), 0 Lux (IR LED On)
Synchronisation: Internal
White balance: Auto
Back light compensation: Auto
Gain control: Auto
Video output signal: Hd Analog Output
Transmission distance: Up to 500m over coaxial cable
Operating conditions: -10°C ~ +60°C, Humidity 90% or less (non-condensing)
Power supply: DC 12V ± 10%
Current, power consumption: 250ma , Max 3.5W
DIMENSION (lxwxh), WEIGHT: 110mm*110mm*88mm, 270g
